HYDROCOOL

RECHARGEABLE COOLING MIST FAN

USER MANUAL

TECHNICAL PARAMETER

1. Charging time: 4–6h
2. Fan working time:
• High: 3h, Mid: 5h, Low: 10h (no oscillating)
• High: 2.5h, Mid: 3.5h, Low: 5.5h (oscillating)
• LED working time: 55h

Misting working time:

• 1 pcs hole: 15h
• 2 pcs holes: 10h
• 3 pcs holes (Low): 10h
• 3 pcs holes (High): 5h
2. Charging voltage: 110–240V 50/60Hz
3. Max power: 11W

WARNING

1. The battery should be properly disposed or recycled after useful life, as it is harmful to the environment.
2. If the supply cord of the fan is damaged, it shall be exclusively replaced by the manufacturer or his service agent or a similar qualified person in order to avoid electric hazard.
3. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
4. Children should be supervised to ensure that they do not play with the appliance.

WARRANTY

This product is guaranteed to be free from all manufacturing defects for a period of (1) year from the date of purchase. Batteries are not included.

ATTENTION

1. Read the instructions carefully before using this product.
2. Please use clean water. Please do not use this product before charging.
3. Long term does not use this product, every three months must be charged to the product.
4. When you do not use this product, please close all work functions.
5. Switch off the power when filling water.
6. Drain and completely dry the water tank and atomizer components before storing the fan for long periods.
7. Replace the water pipe intake filter every three months.

INSTALLATION METHOD

1. Press the latches on both sides of the water tank cover to open it (Figure 1 and Figure 2).
2. Remove the fan unit from the water tank, as shown in Figure 3.
3. Connect the water pipe to the base of the fan unit, as shown in Figure 4.
4. Place the fan unit onto the water tank. Ensure the fan base is securely clipped into the latches on the water tank cover as shown in Figure 5.

FUNCTION DESCRIPTION

1. Automatic AC/DC switching. Overcharge and over-discharge protection for the battery. 4-segment battery level indicator.
2. The fan features an oscillation function and control buttons for ON/OFF, LIGHT, and MIST.
3. ON/OFF Control: A single press of the ON/OFF button will start the fan at low speed. Subsequent presses cycle through Low Speed → Medium Speed → High Speed → OFF. If the fan has been operating at any speed for more than 30 seconds, the next press of the ON/OFF button will switch it to OFF state.
4. Oscillating Function: Pressing the oscillating button while the fan is operating will activate the power-off function. The fan head will automatically return to the centered position upon shutdown.
5. Indicator Lights: The corresponding indicator lights illuminate during fan operation and charging. The lights will automatically turn off after 60 seconds. Pressing any button will relight them.
6. Battery Level Indicator: The battery level is displayed in four segments: 25%, 50%, 75%, and 100%. During charging, the indicators will display a running light pattern. Once a 25% charge segment is full, that indicator remains solid. All four indicators will be solid when the battery is fully charged.
7. MIST Function: Press the MIST button to cycle through the atomization modes:
• 1-Port High Mist
• 2-Port High Mist
• 3-Port Low Mist
• 3-Port High Mist
8. Timer: Timing on the remote control for 1–8 hours

TECHNICAL SPECIFICATIONS

1. Built-in battery: 3.7V/4500mAh lithium rechargeable battery
2. Motor: DC 12V Brushless Motor
3. LED indicators:
• 4 pcs buttons
• 3 pcs white LED speed indicators
• 4 pcs LED battery level indicators
• 4 pcs white LED mist mode indicators
4. LED: 4 pcs LED light
5. Output: USB 5V/1A output port
6. Input: DC 5V/2A USB Type-C
7. Remote control: 12-key infrared remote controller (timing function only controlled by remote)
8. Water tank: 8L

PARTS LIST

1. Control Panel
2. Type-C Input Socket
3. USB Output Socket
4. Handle
5. Battery Cover
6. Water Tank Cap
7. Water Pipe
8. Filter
9. Water Tank
10. Remote
